Precision Grinding Coolant Through Drill Bits Straight Flute Drill For Deep Hole Processing

Precision Grinding Coolant Through Drill Bits Straight Flute Drill For Deep Hole Processing

Brand Name:	AMG
Model Number:	Standard/Customized
MOQ:	3
Price:	Request Quote

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001

Material:

Carbide

Type:

Twist Drill Bit,Core Drill Bit,Various,taper Drill Bit,Glass Drill Bits

Product Name:

Deep Hole Drill For Precision Parts

Coating:

Uncoated/TiAlN /DLC

Hrc:

90-93

Highlight:

Precision Grinding Coolant Through Drill Bits

Straight Flute Drill For Deep Hole

Product Description

High Stability Coolant Through Straight Flute Drill for Deep Hole Processing

Product Specifications

Attribute	Value
Material	Carbide
Type	Twist Drill Bit, Core Drill Bit, Various, Taper Drill Bit, Glass Drill Bits
Product Name	Deep Hole Drill for Precision Parts
Coating	Uncoated/TiAlN/DLC
Hrc	90-93

Product Description

The AMG solid carbide coolant-through straight flute drill is engineered for deep and blind hole machining in machinery structural parts. Manufactured from high-quality ultra-fine grain solid carbide (HM) with precision grinding, it delivers exceptional hardness, wear resistance, and anti-chipping performance for stable operation and high hole accuracy.

Key Features

Internal coolant channel design for direct high-pressure coolant delivery
Rapid heat dissipation and reduced cutting temperatures
Improved chip evacuation and extended tool life
Efficient, stable deep hole drilling capability

Applications

Ideal for deep and blind hole machining in structural components including:

Shafts and jigs
Hydraulic cylinder holes
Mold cooling channels
High-precision drilling in carbon steel, alloy steel, stainless steel, aluminum alloys, and copper alloys

Technical Specifications

Material: Ultra-fine grain solid carbide (HM)
Cooling: Coolant-Through system
Flute Type: Straight Flute design
Diameter Range: Φ3mm - Φ12mm (customizable)
Cutting Length: 6D / 10D / 15D / 20D (customizable)
Coating Options: TiAlN / DLC / Uncoated

Working Principle

The AMG drill's internal coolant channels deliver coolant directly to the cutting area, reducing heat and friction while ensuring proper lubrication. The straight flute design enables smooth chip evacuation and stable guidance, preventing clogging and hole deformation during deep hole drilling operations.

Product Advantages

✓ Efficient coolant-through cooling prevents heat accumulation in deep holes

✓ Smooth chip evacuation reduces clogging risks

✓ Precision ground sharp cutting edges for low resistance cutting

✓ Ensures high hole straightness and dimensional accuracy

✓ Extended tool life reduces downtime for tool changes

Frequently Asked Questions

Q: What materials are suitable for the AMG solid carbide coolant-through straight flute drill?

A: Suitable for carbon steel, alloy steel, stainless steel, aluminum alloys, and copper alloys in structural components.

Q: What should customers consider when selecting the drill?

A: Consider hole diameter, depth, material, and coolant pressure. Choose appropriate cutting lengths (6D, 10D, 15D, 20D) and coatings (TiAlN for stainless steel/hard materials, DLC/uncoated for aluminum/soft materials).

Q: Does AMG offer customized sizes?

A: Yes, AMG supports customization of diameter, cutting length, and coating based on customer drawings and machining requirements.
